SAMSUNG 1.5 Ton Inverter AC

• Model Code: AR18CVFAMWKUFE

• Capacity (Cooling, Btu/hr): 18000 Btu/hr
• Capacity (Cooling, Min – Max, Btu/hr): 5500 – 21500 Btu/hr
• Capacity (Cooling, kW): 5.28 kW
• Capacity (Cooling, Min – Max, kW): 1.61 – 6.3 kW
• EER (Cooling, W/W): 3.26 W/W
• EER (Cooling, Btu/hW): 11.11 Btu/hW
• CSPF: 3.24
• Energy Star Rating (Cooling): 1.5 Star
• Noise Level (Indoor, High/Low, dBA): 44/28 dBA
• Noise Level (Outdoor, High/Low, dBA): 53 dBA
• Power Source(Φ/V/Hz): 1 / 230 / 50
• Power Consumption(Cooling, W): 1620 W
• Operating Current(Cooling, A): 7.4 A
• Gross Dimension (Indoor, WxHxD, ㎜*㎜*㎜): 1115*290*375 mm
• Gross Dimension (Outdoor, WxHxD, ㎜*㎜*㎜): 913*622*371 mm
• Net Dimension (Indoor, WxHxD, ㎜*㎜*㎜): 1055*299*215 mm
• Net Dimension (Outdoor, WxHxD, ㎜*㎜*㎜): 790*548*285 mm
• Gross Weight (Indoor, kg): 13.20 kg
• Gross Weight (Outdoor, kg): 36.30 kg
• Net Weight (Indoor, kg): 11.60 kg
• Net Weight (Outdoor, kg): 32.00 kg
• Loading Quantity (20/40/40Hft without Pipe): 80/168/198
• SVC Valve (Liquid (ODxL): 6.35
• SVC Valve (Gas (ODxL): 12.7
• Moisture Removal (l/hr): 2.0 l/hr
• Air Circulation (Cooling, ㎥/min): 17.9 ㎥/min
• Refrigerant (Type): R410A
• Refrigerant (Charging, kg): 1.25 kg
• Refrigerant (Charging, tCO2e): 2.61 tCO2e
• Low Ambient (Cooling, ℃): 16 ~ 46 ℃
• Outdoor Unit (Compressor Type): BLDC
• Air Direction Control (Up/Down): Auto
• Air Direction Control (Left/Right): Auto
• Air Flow Control Step (Cool/Fan): 4-May
• Features:   WindFree Cooling, Copper Anti-bacterial Filter,Auto Clean (Self Cleaning), SmartThings, AI Auto Cooling, Freeze Wash, Filter Cleaning Indicatior, Indoor Temp. Display, Display On/Off, 24-Hour Timer, Auto Restart, Auto Mode, Fast Cool, Good Sleep, Eco Mode, Dehumidification, Fan Mode, Quiet, WiFi Embedded, SmartThings App Support.
• SAMSUNG 1.5 Ton Inverter AC

Always stay warm when it is freezing

Max Heat

Stay comfortably warm all year round even in extremely cold conditions. Max Heat ensures that the air conditioner provides a 100% heating performance when it is as low as -4℉* outside. It will even continue working reliably and heat your home effectively in freezing temperatures of -22℉**.

Stay comfortably warm all year round even in extremely cold conditions. Max Heat ensures that the air conditioner provides a 100% heating performance when it is as low as -4℉* outside. It will even continue working reliably and heat your home effectively in freezing temperatures of -22℉**

Enjoy an even temperature across a room

4-way Swing

Create a comfortable environment with an even temperature in every corner of a room. The 4-way Swing function lets you remotely control the air direction or automatically expels air in every direction. As well as the auto up-down swing function it also has an auto left-right swing function.

Create a comfortable environment with an even temperature in every corner of a room. The 4-way Swing function lets you remotely control the air direction or automatically expels air in every direction. As well as the auto up-down swing function it also has an auto left-right swing function.

Automatically stays fresh and hygienic

3-step Auto Clean

Keep the inside of the air conditioner hygienic by doing nothing! After it’s been working, the Auto Clean function automatically dries the Heat Exchanger using a 3-step process. It removes moisture by blowing air for between 10 to 30 minutes***.

Keep the inside of the air conditioner hygienic by doing nothing! After it’s been working, the Auto Clean function automatically dries the Heat Exchanger using a 3-step process. It removes moisture by blowing air for between 10 to 30 minutes***.

Automatically use up to 20% less energy

SmartThings AI Energy Mode

Monitor and reduce the air conditioner’s energy use. AI Energy mode* lets you check the power use and estimates the electricity bill. By learning your usage patterns and analyzing the room conditions, it reduces energy use by up to 20%** by adjusting the temperature*** and compressor frequency.

Cool more, sleep more

Cools efficiently

Motion Detect Sensor

Cools efficiently

Motion Detect Sensor

Simply smart control with a touch or voice

SmartThings

Control the air conditioner anytime and anywhere. The SmartThings App* lets you remotely control and monitor it with a touch. Using a voice recognition assistant**, like Samsung Bixby***, Amazon Alexa**** or Google Assistant*****, you can tell it what to do. It even suggests the best settings.

Control the air conditioner anytime and anywhere. The SmartThings App* lets you remotely control and monitor it with a touch. Using a voice recognition assistant**, like Samsung Bixby***, Amazon Alexa**** or Google Assistant*****, you can tell it what to do. It even suggests the best settings.

Corrosion-resistant for added durability

DuraFin+

Stay comfortably cool for much longer. The DuraFin+ is made of corrosion-resistant material to protect the condenser from rusting, which helps to maintain the optimal performance of the Heat Exchanger. Its superb corrosion-resistance was proven using the Salt Spray Test (SST) for 480 hours

Stay comfortably cool for much longer. The DuraFin+ is made of corrosion-resistant material to protect the condenser from rusting, which helps to maintain the optimal performance of the Heat Exchanger. Its superb corrosion-resistance was proven using the Salt Spray Test (SST) for 480 hours

Easy to clean anti-bacterial filter

Easy Filter Plus

Keep your air conditioner working efficiently with less effort. The Easy Filter Plus is located outside, on the top, so it can easily be taken out and cleaned. Its dense mesh keeps the Heat Exchanger clean and an anti-bacterial coating helps protect you against dangerous airborne contaminants

Removes fine dust and harmful material

4-in-1 Care Filter

4-in-1 Care Filter includes air filter media that collects household dust, including particles as small as PM2.5, as well as fibers and hair. It also has a filter with a Copper coating that removes up to 99% of viruses, bacteria, allergens and PM2.5 dust

Saves energy & money, cools effectively

ECO Mode

Save energy, but still stay cool. ECO mode uses less compressor capacity compared to Normal mode, which reduces energy consumption*. It lets you cool more efficiently when it’s not too hot outside or just save energy and money at any time, so you don’t have to worry about the electricity bills.

Enjoy a good night’s sleep& save energy

WindFree™ Good Sleep

Get a really good night’s sleep every night. The WindFree™ Good Sleep mode creates the ideal climate for sleeping – without an unpleasant cold air flow. Its temperature control with WindFree™ cooling helps you fall asleep fast, sleep deeply and comfortably and wake up feeling fully refreshed

Enjoy an even temperature across a room

4-way Swing

Create a comfortable environment with an even temperature in every corner of a room. The 4-way Swing function lets you remotely control the air direction or automatically expels air in every direction. As well as the auto up-down swing function it also has an auto left-right swing function.

Less risk of electric damage & accidents

Power Volt

Stop worrying about the voltage of your electrical supply. Brazil has similar looking 127V and 220V power outlets, which causes damage when appliances are plugged into the wrong voltage. So the air conditioner has a Power Volt* function and can be safely used anywhere on either voltage

Long-lasting protection, optimal cooling

Triple Protector Plus

Enjoy a long-lasting performance in challenging environments. Triple Protector Plus technology prevents damage from power surges and fluctuating electrical currents, without a separate voltage stabilizer*. Its anti-corrosion coating also protects the condenser and cabinet in harsh conditions.

More efficient Heat Exchanger performance

DuraFin

Enhance the performance and efficiency of the Heat Exchanger using the DuraFin. It is made of a much denser material and is thicker in design. Its improved coating also has more corrosion resistance. So it passes the accelerated Sea Water Acetic Acid Test (SWAAT) for corrosion over 100 days

Optimized comfort, more energy savings

Digital Inverter Boost

Save money every day with highly energy-efficient Digital Inverter Boost technology. It maintains the desired temperature with less fluctuation. It also has strong magnets and a Muffler, so it works efficiently and produces less noise and vibration. And it reduces energy usage by up to 73%

Save money every day with highly energy-efficient Digital Inverter Boost technology. It maintains the desired temperature with less fluctuation. It also has strong magnets and a Muffler, so it works efficiently and produces less noise and vibration. And it reduces energy usage by up to 73%

Personalized comfort welcomes you home

Welcome Cooling (with Geofencing functionality)

Feel comfortably cool as soon as you get home. Welcome Cooling, part of the SmartThings App*, detects your location by tracking your phone’s GPS**. When you come within a preset distance, it automatically sets the room temperature at the desired level, using your preferred mode and settings.

Refreshingly gentle

WindFree™ Metal Cooling

Stay comfortable with WindFree™ Metal Cooling. It gently and quietly disperses air through 23,800 micro air holes in a real metal panel, so there is no unpleasant feeling of cold wind on your skin. It also cools a wider and larger area more evenly and uses 77% less energy than Fast Cooling

Removes fine dust and harmful material

4-in-1 Care Filter

4-in-1 Care Filter includes air filter media that collects household dust, including particles as small as PM2.5, as well as fibers and hair. It also has a filter with a Copper coating that removes up to 99% of viruses, bacteria, allergens and PM2.5 dust*

Removes fine dust, viruses & allergens

Tri-Care Filter

Tri-Care Filter includes a high-density filter that extracts large dust, fibers and hairs. It also has a Zeolite Coating Filter that captures fine dust and removes up to 99.9% of viruses and bacteria* as well as 98% of allergens

Saves energy & money, cools effectively

ECO Mode

Save energy, but still stay cool. ECO mode uses less compressor capacity compared to Normal mode, which reduces energy consumption*. It lets you cool more efficiently when it’s not too hot outside or just save energy and money at any time, so you don’t have to worry about the electricity bills

Simply smart control with a touch or voice

SmartThings

Control the air conditioner anytime and anywhere. The SmartThings App* lets you remotely control and monitor it with a touch. Using a voice recognition assistant**, like Samsung Bixby***, Amazon Alexa**** or Google Assistant*****, you can tell it what to do. It even suggests the best settings

Simply wash inside to optimize performance

Freeze Wash

Maintain the optimum performance with the push of a button. Freeze Wash* quickly freezes the Heat Exchanger and then defrosts the ice. So it is washed in water, which removes dirt and 95% of microorganisms**. Finally, it dries up any moisture. And it alerts you when it is time for a clean

Smart energy savings

SmartThings Energy

Control energy usage to reduce your bills. SmartThings Energy* lets you easily check your power consumption**. If the estimated amount*** exceeds your target, it adjusts the energy usage of all smart appliances. When the air conditioner is on it draws the blinds and alerts you if you go out.

Solar-powered, prevents low battery

Solarcell Remote Controller

Protect the environment and never worry about batteries again! The eco-friendly Samsung Solarcell Remote Controller has a small solar panel on the back, so you can keep it powered using the light of the sun or the ambient light in a room. You can also recharge it using a C-type USB connector.

Stay comfortably cool

WindFree™ Cooling

Stay comfortable cool with WindFree™ Cooling. It gently and quietly disperses air through 23,000 micro air holes, so there is no unpleasant feeling of cold wind on your skin. Its advanced airflow also cools a wider and larger area more evenly. And it uses 77% less energy than Fast Cooling

Trendy modern look

WindFree™ BLACK

Give your home a real touch of style with an elegantly modern look that reflects the current trend for dark colors. “WindFree™ BLACK ” finish is a deep dark color that blends in harmoniously with the luxurious dark tones of modern interiors and will look good in almost any room in your house

Warms rooms faster

Fast Heating

Heat rooms quickly from corner to corner, so you are always comfortable whenever you want and wherever you are. When activated, the Fast Heating mode quickly distributes warm air across an entire room. Its unique design means it reaches the desired temperature faster than conventional models

Enjoy a quieter & more tranquil home

Less Noise

Cool your living spaces with less noise, so it doesn’t disturb you. The compressor creates a powerful airflow, but works really quietly as it includes a Twin Tube Muffler. It reduces the refrigerant flow noise when operating at high speed and minimizes ambient noise during low speed operation.
